» Separatoare de sarcina - Butoane si accesorii IP65

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

590.HEL6302

SWITCH DISCONNECTOR 63A 2P IP65 SCAME 590.HEL6302

Cod EAN: 8001636293431

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 611.52 Lei / 1

Pret cu TVA: 739.94 Lei / 1

«« Inapoi

Inainte »»

Master data
1NR Minimum order: 0KG Net Weight: 8001636293431 EAN code: 85365080 INTRASTAT code:

TechData
ISOLATORS Series Commercial series: SWITCH DISCONNECTOR Synthetical description: IP65 Protection degree: GENERAL Type: YELLOW/RED Colour: 63A Rated current: 2P Poles: Y2 Switch size: 150x210x107mm Dimensions: LUCCHETTABILI ON-OFF Notes:

Packaging
Carton Description: 5 Quantity: 8001636741581 EAN code: 0 KG Gross weight: 0 Volume: 0X0X0 () Dimensions: Box Description: 1 Quantity: EAN code: 0 KG Gross weight: 0 Volume: 0X0X0 () Dimensions:

Note:

Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position

Equipped with door interlock

Open threaded cable entry with cap / cable sleeve

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
