Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.
590.JEM4005
SWITCH DISCONNECTOR 40A 3P+N IP66 SCAME 590.JEM4005
Cod EAN: 8001636294759
Marca: Scame
Cantitate minima: 1
Pret fara TVA: 679.03 Lei / 1
Pret cu TVA: 821.63 Lei / 1
SWITCH DISCONNECTOR 40A 3P+N IP66 SCAME 590.JEM4005
1NR
Minimum order:
0.77KG
Net Weight:
8001636294759
EAN code:
85365080
INTRASTAT code:
Commercial series:
SWITCH DISCONNECTOR
Synthetical description:
IP66
Protection degree:
EMERGENCY
Type:
YELLOW/RED
Colour:
40A
Rated current:
3P+N
Poles:
Y1
Switch size:
226x306x115mm
Dimensions:
-25 °C
Ambient temperature Ta min:
60 °C
Ambient temperature Ta max:
Carton
Description:
12
Quantity:
8001636742380
EAN code:
10.644 KG
Gross weight:
51600 CCM
Volume:
300X400X430 (MM)
Dimensions:
Box
Description:
1
Quantity:
EAN code:
0.887 KG
Gross weight:
3339.201 CCM
Volume:
142X183X128.5 (MM)
Dimensions:
EN 60947-3 (2006)
View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
