» Separatoare de sarcina - Butoane si accesorii IP65

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

590.YA405B

SWITCH DISCONNECTOR 40A 3P+N B SCAME 590.YA405B

Cod EAN: 8001636265100

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 147.51 Lei / 1

Pret cu TVA: 178.49 Lei / 1

Inainte »»

Master data
6NR Minimum order: 0.116KG Net Weight: 8001636265100 EAN code: 85365080 INTRASTAT code:

TechData
COMMAND Series Commercial series: SWITCH DISCONNECTOR Synthetical description: BOX (B) Type: 40A Rated current: 3P+N Poles: Y1 Switch size:

Packaging
Box Description: 6 Quantity: 8001636711263 EAN code: 0.768 KG Gross weight: 3833.027 CCM Volume: 163X183X128.5 (MM) Dimensions:

Note:

BOX (B) = Base mounting

DIN rail fixing

With late break and early make neutral pole

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1/A2 (2014) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A2 (2015) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units

Annexed
