590.HGE3203

SWITCH DISCONNECTOR 32A 3P IP65 SCAME 590.HGE3203

Cod EAN: 8001636140698

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 264.29 Lei / 1

Pret cu TVA: 319.79 Lei / 1

«« Inapoi

Inainte »»

Master data
1NR Minimum order: 0.863KG Net Weight: 8001636140698 EAN code: 85365080 INTRASTAT code:

TechData
ISOLATORS Series Commercial series: SWITCH DISCONNECTOR Synthetical description: IP65 Protection degree: GENERAL Type: GREY/BLACK Colour: 32A Rated current: 3P Poles: Y1 Switch size: 105x150x82mm Dimensions:

Packaging
Carton Description: 12 Quantity: 8001636572031 EAN code: 11.64 KG Gross weight: 36800 CCM Volume: 320X460X250 (MM) Dimensions: Box Description: 1 Quantity: 8001636572024 EAN code: 0.97 KG Gross weight: 2121.168 CCM Volume: 107X168X118 (MM) Dimensions:

Note:

Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position

Equipped with door interlock

Open threaded cable entry with cap / cable sleeve

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
