» Separatoare de sarcina - Butoane si accesorii IP65

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

590.HGE2003

SWITCH DISCONNECTOR 20A 3P IP65 SCAME 590.HGE2003

Cod EAN: 8001636189680

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 181.48 Lei / 1

Pret cu TVA: 219.59 Lei / 1

Inainte »»

Master data
1NR Minimum order: 0.865KG Net Weight: 8001636189680 EAN code: 85365080 INTRASTAT code:

TechData
ISOLATORS Series Commercial series: SWITCH DISCONNECTOR Synthetical description: IP65 Protection degree: GENERAL Type: GREY/BLACK Colour: 20A Rated current: 3P Poles: Y1 Switch size: 105x150x82mm Dimensions:

Packaging
Carton Description: 12 Quantity: 8001636644295 EAN code: 11.64 KG Gross weight: 36800 CCM Volume: 320X460X250 (MM) Dimensions: Box Description: 1 Quantity: 8001636644288 EAN code: 0.97 KG Gross weight: 2121.168 CCM Volume: 107X168X118 (MM) Dimensions:

Note:

Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position

Equipped with door interlock

Open threaded cable entry with cap / cable sleeve

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units

Annexed
