» Fise si prize industriale IP44/IP67

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

530.32134

SOCKET OUTLET 3P IP44 32A 3h 20-25V SCAME 530.32134

Cod EAN: 8001636089485

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 89.99 Lei / 1

Pret cu TVA: 108.89 Lei / 1

«« Inapoi

Inainte »»

Master data
10NR Minimum order: 0.231KG Net Weight: 8001636089485 EAN code: 85366990 INTRASTAT code:

TechData
IEC309 Series Commercial series: SURFACE MOUNTING SOCKET Synthetical description: 32A Rated current: 3P Poles: 3h Hour position: 20-25V Rated voltage: 40-50V Rated voltage: 400Hz Working frequency: GREEN Colour: IP44 Protection degree: STRAIGHT Types of available outlets: Screw terminals Terminals: DRILLING POINT MARK Cable outlet:

Packaging
Carton Description: 50 Quantity: 8001636504483 EAN code: 12.75 KG Gross weight: 66990 CCM Volume: 385X580X300 (MM) Dimensions: Box Description: 10 Quantity: 8001636504490 EAN code: 2.55 KG Gross weight: 9450.54 CCM Volume: 258X333X110 (MM) Dimensions:

Note:

Blank side with drilling point mark

Rubber cable sleeve included

Approvals and Certifications

I.M.Q. - ENEC 03

Standards and Laws

	EN 60309-2 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations
	EN 60309-1 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
