» Fise si prize industriale IP44/IP67

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

430.1618

SOCKET OUTLET 3P IP44 16A 12h 40-50V AC SCAME 430.1618

Cod EAN: 8001636005843

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 50.02 Lei / 1

Pret cu TVA: 60.52 Lei / 1

«« Inapoi

Inainte »»

Master data
10NR Minimum order: 0.146KG Net Weight: 8001636005843 EAN code: 85366990 INTRASTAT code:

TechData
IEC309 Series Commercial series: FLUSH-MOUNTING SOCKET Synthetical description: 16A Rated current: 3P Poles: 12h Hour position: 40-50V Rated voltage: 50Hz Working frequency: 60Hz Working frequency: WHITE Colour: IP44 Protection degree: ANGLED Types of available outlets: Screw terminals Terminals: 70X87MM Flange:

Packaging
Carton Description: 100 Quantity: 8001636970714 EAN code: 16.8 KG Gross weight: 72450 CCM Volume: 375X560X345 (MM) Dimensions: Box Description: 10 Quantity: 8001636994161 EAN code: 1.68 KG Gross weight: 5428 CCM Volume: 115X295X160 (MM) Dimensions:

Approvals and Certifications

I.M.Q. - ENEC 03

Standards and Laws

	EN 60309-1 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
	EN 60309-2 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations

Annexed
