» Fise si prize industriale IP44/IP67

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

435.3215

SOCKET OUTLET 2P IP67 32A 20-25V AC 50Hz SCAME 435.3215

Cod EAN: 8001636054391

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 49.91 Lei / 1

Pret cu TVA: 60.39 Lei / 1

«« Inapoi

Inainte »»

Master data
10NR Minimum order: 0.149KG Net Weight: 8001636054391 EAN code: 85366990 INTRASTAT code:

TechData
IEC309 Series Commercial series: FLUSH-MOUNTING SOCKET Synthetical description: 32A Rated current: 2P Poles: 20-25V Rated voltage: 50Hz Working frequency: 60Hz Working frequency: VIOLET Colour: IP66/IP67 Protection degree: ANGLED Types of available outlets: Screw terminals Terminals: 70X87MM Flange:

Packaging
Carton Description: 100 Quantity: 8001636914602 EAN code: 17.2 KG Gross weight: 70297.5 CCM Volume: 260X525X515 (MM) Dimensions: Box Description: 10 Quantity: 8001636914619 EAN code: 1.72 KG Gross weight: 5683.47 CCM Volume: 236X247X97.5 (MM) Dimensions:

Approvals and Certifications

I.M.Q. - ENEC 03

Standards and Laws

	EN 60309-1 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
	EN 60309-2 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations

Annexed
