» Separatoare de sarcina - Butoane si accesorii IP65

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

590.GE4002

ISOLATOR 40A 2P IP65 SCAME 590.GE4002

Cod EAN: 8001636164670

Marca: Scame

Cantitate minima: 12

Pret fara TVA: 317.33 Lei / 1

Pret cu TVA: 383.97 Lei / 1

Inainte »»

Master data
1NR Minimum order: 0.83KG Net Weight: 8001636164670 EAN code: 85365080 INTRASTAT code:

TechData
ISOLATORS Series Commercial series: SWITCH DISCONNECTOR Synthetical description: IP65 Protection degree: GENERAL Type: GREY/BLACK Colour: 40A Rated current: 2P Poles: Y1 Switch size: 136x125x84mm Dimensions:

Packaging
Carton Description: 12 Quantity: 8001636630939 EAN code: 12.264 KG Gross weight: 51600 CCM Volume: 300X400X430 (MM) Dimensions: Box Description: 1 Quantity: 8001636603766 EAN code: 1.022 KG Gross weight: 3339.201 CCM Volume: 142X183X128.5 (MM) Dimensions:

Note:

OMNIA Series enclosure

Blank side with drilling point mark

Equipped with door interlock

Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units

Annexed
