» Separatoare de sarcina - Butoane si accesorii IP65

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

590.GE2004

ISOLAT.20A 4P IP65 SURF.M.PLAST.BOX GEN SCAME 590.GE2004

Cod EAN: 8001636189888

Marca: Scame

Cantitate minima: 12

Pret fara TVA: 232.00 Lei / 1

Pret cu TVA: 280.72 Lei / 1

«« Inapoi

Inainte »»

Master data
1NR Minimum order: 0.442KG Net Weight: 8001636189888 EAN code: 85365080 INTRASTAT code:

TechData
ISOLATORS Series Commercial series: SWITCH DISCONNECTOR Synthetical description: IP65 Protection degree: GENERAL Type: GREY/BLACK Colour: 20A Rated current: 4P Poles: Y1 Switch size: 136x125x84mm Dimensions:

Packaging
Carton Description: 12 Quantity: 8001636644622 EAN code: 7.044 KG Gross weight: 51600 CCM Volume: 300X400X430 (MM) Dimensions: Box Description: 1 Quantity: 8001636644615 EAN code: 0.587 KG Gross weight: 3339.201 CCM Volume: 142X183X128.5 (MM) Dimensions:

Note:

OMNIA Series enclosure

Blank side with drilling point mark

Equipped with door interlock

Handle padlockable in OFF (3 padlocks) and ON (1 padlock) position

Approvals and Certifications

View certificate

Standards and Laws

	EN 60947-3 (2006) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
	EN 60947-1 (2007) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-1/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear - Part 1: General rules
	EN 60947-3/A1 (2011) View certificate
[European Standard] Low-voltage switchgear and controlgear Part 3: Switches, disconnectors, switch-disconnectors and fuse-combination units
