405.2416

INTERLOCKED SOCKET 2P IP67 16A 20-25V AC SCAME 405.2416

Cod EAN: 8001636073880

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 857.55 Lei / 1

Pret cu TVA: 1037.64 Lei / 1

«« Inapoi

Master data
6NR Minimum order: 1.427KG Net Weight: 8001636073880 EAN code: 85366990 INTRASTAT code:

TechData
OMNIA Series Commercial series: INTERLOCKED SOCKET Synthetical description: 16A Rated current: 2P Poles: 20-25V Rated voltage: 50Hz Working frequency: 60Hz Working frequency: VIOLET Colour: IP66/IP67 Protection degree: 136X125MM Flange:

Packaging
Carton Description: 6 Quantity: 8001636885094 EAN code: 8.946 KG Gross weight: 17812.5 CCM Volume: 150X475X250 (MM) Dimensions:

Note:

SELV transformer 220/24V~ 60VA ( continuous duty)

Unsuitable for ADVANCE2 System. Use box ref. 572.0309

When plug is inserted a micro-switch is activated and closes the circuit

Approvals and Certifications

View certificate

Standards and Laws

	EN 60309-1 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
	EN 60309-2 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations

Annexed
