» Fise si prize industriale IP44/IP67

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

500.2421

INTERLOCKED SOCKET 2P IP44 16A 12h SCAME 500.2421

Cod EAN: 8001636073941

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 499.20 Lei / 1

Pret cu TVA: 604.03 Lei / 1

«« Inapoi

Inainte »»

Master data
6NR Minimum order: 0.643KG Net Weight: 8001636073941 EAN code: 85366990 INTRASTAT code:

TechData
OMNIA Series Commercial series: INTERLOCKED SOCKET Synthetical description: 16A Rated current: 2P Poles: 12h Hour position: 40-50V Rated voltage: 50Hz Working frequency: 60Hz Working frequency: WHITE Colour: IP44 Protection degree: 136X125MM_PAR Flange:

Packaging
Carton Description: 6 Quantity: 8001636885032 EAN code: 4.488 KG Gross weight: 18427.5 CCM Volume: 315X390X150 (MM) Dimensions:

Note:

The versions without transformer are particularly suitable for installations with centralised extra-low voltage transformer.

Blank side with drilling point mark

Note: in case of mounting with ADVANCE2 System, use METRIC drilling point mark.

When plug is inserted a micro-switch is activated and closes the circuit

OMNIA Series
Flange 136x125mm

Approvals and Certifications

I.M.Q.

Standards and Laws

	EN 60309-1 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
	EN 60309-2 (1999) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations
	EN 60309-1/A1 (2007) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 1: General requirements
	EN 60309-2/A1 (2007) View certificate
[European Standard] Plugs, socket-outlets and couplers for industrial purposes. Part 2: Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations

Annexed
