» Presetupe si accesorii ip66/ip68

Fotografiile prezentate au caracter informativ, pot diferi fata de produsul vandut, acesta fiind livrat conform codului oferit de producator.

805.5425.0

CABLE GLAND M25X1,5 NO NUT LIGHT SCAME 805.5425.0

Cod EAN: 8001636143675

Marca: Scame

Cantitate minima: 1

Pret fara TVA: 2.52 Lei / 100

Pret cu TVA: 3.05 Lei / 100

«« Inapoi

Inainte »»

Master data
25NR Minimum order: 17.12G Net Weight: 8001636143675 EAN code: 85369010 INTRASTAT code:

TechData
UNION Series Commercial series: CABLE GLAND Synthetical description: IP66 Protection degree: LIGHT Type: GREY Colour: M25X1,5 Thread: ø25mm Fixing hole: ø13-18mm Cable size: 33mm Spanner size: 14mm Thread length: 9N/m Nut spanner coupler: 5,5N/m Seal spanner coupler:

Packaging
Box Description: 25 Quantity: 8001636572468 EAN code: 530.5 G Gross weight: 0 Volume: 0X0X0 () Dimensions: Carton Description: 400 Quantity: 8001636572475 EAN code: 8488 G Gross weight: 45696 CCM Volume: 320X560X255 (MM) Dimensions:

Note:

STANDARD version: IP66

Cable glands are provided without gasket

Approvals and Certifications

View certificate

Standards and Laws

Annexed
